GENERAL MERCHANDISER ILLUSTRATION - MODEL BD3632IS - PAGE 3 of 4
3. Self-Contained Hot Gas Loop Condensate Package (Shown Rotated 180°)
• Caution: Only trained service providers are to provide maintenance and service to unit.
• Warning! Disconnect power before providing maintenance and service to unit.
• Important: Carefully read all Warning/Caution/Danger labels on unit!
Compressor
Filter Dryer
Compressor
Inverter
Condenser Fan
& Housing
Courtesy Loop
Condenser Coil
Housing
Hot Gas Loop
Condensate
Pan
Refrigeration
Lines
