Blend® User Manual 10
Product Placement
Product Placement
Product can be placed on decking or shelves. Proper airow is critical to maintaining proper product temperature.
Product should not be placed on air grills inside of the case and have a least 1 inch of clearance between product and
shelf. See load line illustration below.
Load Line
Air Deector
Load Line at Front of Shelvse
Top
Plenum
Air Diffuser
Product Stop
Sample Product
Load Line
Sample Product
1” Minimum Load Line
from Rear Plenum
1” Minimum
Load Line
1” Minimum
Load Line
1” Minimum Load Line
Below Air Diffuser
1” Minimum Load Line
from Rear Plenum
