Condition LEDs on the
operating unit
LEDs on the
battery
Cause Remedy
device is too
large.
► If the blower still cannot be
found with the STIHL connec‐
ted App: Contact an authorized
STIHL servicing dealer for
assistance.
25 Specifications
25.1 STIHL BRA 500.0 B
–
Approved battery types:
–
STIHL AP series (AP 300, AP 300 S, AP
500 S only)
–
Blowing force: 32 N
–
Maximum air velocity: 243 mph (109 m/s)
–
Average air velocity: 203 mph (91 m/s)
–
Air flow rate: 847 cf/min (1440 m
3
/h)
–
Air flow rate (without blowing unit): 998 cf/min
(1697 m³/h)
–
Weight without battery: 22.3 lbs. 10.1 kg)
–
Bluetooth
®
interface
–
Data transmission protocol: Bluetooth
®
5.1.
The mobile receiving devices must be com‐
patible with Bluetooth
®
Low Energy 5.0 and
support the Generic Access Profile (GAP).
–
Frequency band: ISM band 2.4 GHz
–
Radiated maximum transmission power:
1 mW
–
Bluetooth
®
signal range: maximum 33 ft.
(10 m). The signal range may vary depend‐
ing on ambient conditions and the perform‐
ance of the designated receiving device,
i.e., smartphone or tablet. The Bluetooth
®
range may be significantly limited when the
signal is transmitted through metallic barri‐
ers (e.g., walls, shelving units, etc.) or near
strong electromagnetic fields.
–
Minimum mobile terminal device (e.g., tab‐
let, smartphone) system requirements:
Android or iOS (in current version or higher)
For technical information regarding the STIHL
AP series batteries, see the product information
accompanying your battery.
For technical information regarding the STIHL AL
101, 301, 301-4, 500 and 501 series chargers,
see the product information accompanying your
charger.
Batteries, chargers and other accessories sold
separately. Contact your authorized STIHL serv‐
icing dealer for pricing and availability.
25.2 STIHL BRA 600.0 B
–
Approved battery types:
–
STIHL AP series (AP 300, AP 300 S, AP
500 S only)
–
Blowing force: 35 N
–
Maximum air velocity:252 mph (113 m/s)
–
Average air velocity: 212 mph (95 m/s)
–
Air flow rate: 882 cf/min (1500 m
3
/h)
–
Air flow rate (without blowing unit): 1038 cf/min
(1765 m³/h)
–
Weight without battery: 22.3 lbs. 10.1 kg)
–
Bluetooth
®
interface
–
Data transmission protocol: Bluetooth
®
5.1.
The mobile receiving devices must be com‐
patible with Bluetooth
®
Low Energy 5.0 and
support the Generic Access Profile (GAP).
–
Frequency band: ISM band 2.4 GHz
–
Radiated maximum transmission power:
1 mW
–
Bluetooth
®
signal range: maximum 33 ft.
(10 m). The signal range may vary depend‐
ing on ambient conditions and the perform‐
ance of the designated receiving device,
i.e., smartphone or tablet. The Bluetooth
®
range may be significantly limited when the
signal is transmitted through metallic barri‐
ers (e.g., walls, shelving units, etc.) or near
strong electromagnetic fields.
–
Minimum mobile terminal device (e.g., tab‐
let, smartphone) system requirements:
Android or iOS (in current version or higher)
For technical information regarding the STIHL
AP series batteries, see the product information
accompanying your battery.
For technical information regarding the STIHL AL
101, 301, 301-4, 500 and 501 series chargers,
see the product information accompanying your
charger.
Batteries, chargers and other accessories sold
separately. Contact your authorized STIHL serv‐
icing dealer for pricing and availability.
25.3 STIHL AP Series Battery
Approved charger types: STIHL AL 101, AL 300,
AL 301, AL 301-4, AL 500, AL 501.
–
Battery technology: Lithium-Ion
–
Voltage: 36 V
–
Rated capacity in Ah
1
: See rating plate
25 Specifications English
0458-060-8601-A 25
