2.2 Warning Notices in Text
DANGER
■ This notice refers to risks which result in seri‐
ous or fatal injury.
► Serious or fatal injuries can be avoided by
taking the precautions mentioned.
WARNING
■ This notice refers to risks which can result in
serious or fatal injury.
► Serious or fatal injuries can be avoided by
taking the precautions mentioned.
NOTICE
■ This notice refers to risks which can result in
damage to property.
► Damage to property can be avoided by tak‐
ing the precautions mentioned.
2.3 Symbols in Text
This symbol refers to a chapter in this
instruction manual.
3 Overview
3.1 Pruning shears
12
15
#
16
3
20
18
17
#
4
1
2
9
8
10
11
12
13
14
19
7
6
5
#
0000101442_002
1 Anvil blade
The anvil blade serves as a support for the
branch.
2 Cutting blade
The cutting blade cuts the branch.
3 Blade protection
The blade protection protects the user against
contact with the blades.
4 Display
The display shows information and errors.
5
Display
The display shows the state of charge of the
battery.
6
Display
The display shows the configured opening
width of the blade.
7 Number of cuts display
The display shows the total number of cuts.
8 Bracket for combination wrench
The bracket is used for storing the combina‐
tion wrench in the battery compartment.
3 Overview English
0458-059-9601-A 27
