– 36 –

Contents

10. Technical specifications

– Dimensions (H×W×D): 49.8×43.0×15.1mm

– Voltage range: 9.5VDC – 22.5VDC

(in accordance with IEC62368-101)

– Typical DALI current consumption (at 16.5V): 2.7mA

– Max. DALI current consumption

(starting current at 22.5 V): 9mA

– DALI-2 addresses: 1

– Input via: floating push-button/switch

– Number of inputs: 4

– Input terminal labelling: K1,K2,K3,K4

– Max. cable length: 50m

– Max. housing temperature: 75°C

– Protection class: II. When used in the intended manner

– IP rating: IP20

– Ambient temperature: - 20°Cto+ 50°C

11. Troubleshooting

Unit without power.

– Fuse not switched ON or faulty.

• Switch ON fuse.

• Change faulty fuse.

– Break in wiring.

• Check wiring with voltage tester.

– Short circuit in mains power supply lead.

• Check connections.

– Any mains switch OFF

• Switch ON mains switch.
