6.5 Audio Montage Colors 91
6.4.2 Oscilloscope
The Oscilloscope offers a highly magnified view of the waveform around the playback cursor
position.
If you are analyzing a stereo file, the Oscilloscope normally shows the separate levels of
the two channels. However, if you activate the option "Show Sum and Subtraction" on the
Functions menu (or click the +/- icon), the upper half of the Oscilloscope shows the sum of
the two channels and the lower half shows the subtraction.
Making settings
By opening the Settings dialog you can adjust the display colors, and choose to activate
Auto-zoom or not. With Auto-zoom activated, the display is optimized so that the highest
level reaches the top of the display at all times. The Settings dialog can be accessed through
the Functions > Settings... menu, or by using the icon.
The Oscilloscope can be found in the Meters menu of the Audio Files and Audio Montage
Workspaces. It can be used either as a floating window, or docked in the Workspace.
Related topics
Metering
6.4.3 Spectroscope
The Spectroscope shows a continuous graphical representation of the frequency spectrum,
analyzed into 60 separate frequency bands, represented as vertical bars. Peak levels are
shown as a short horizontal lines above the corresponding band, indicating recent peak/-
maximum values.
The Spectroscope can be found in the Meters menu of the Audio Files and Audio Montage
Workspaces. It can be used either as a floating window, or docked in the Workspace.
Related topics
Metering
6.5 Audio Montage Colors
You can create and assign different color schemes to different Clips and parts of a Clip, to
help you find your way through the Montage.
Default colors are provided, but you can also define custom colors. To define a new color
scheme, select the color name to be defined (click once and overtype to rename), select the
parts to which it is applied, then define the color value using the color wheel (or type a set
of RGB - Red, Green, Blue values).
You can use the Copy color and Paste buttons to transfer colors between various parts of
the montage. In addition, you can drag groups of color settings onto another location in the
