6.2 Transport controls 83
If you are analyzing a stereo file, the Oscilloscope normally shows the separate levels of
the two channels. However, if you activate the option "Show Sum and Subtraction" on the
Functions menu (or click the +/- icon), the upper half of the Oscilloscope shows the sum of
the two channels and the lower half shows the subtraction.
Making settings
By opening the Settings dialog you can adjust the display colors, and choose to activate
Auto-zoom or not. With Auto-zoom activated, the display is optimized so that the highest
level reaches the top of the display at all times. The Settings dialog can be accessed through
the Functions > Settings... menu, or by using the icon.
The Oscilloscope can be found in the Meters menu of the Audio Files and Audio Montage
Workspaces. It can be used either as a floating window, or docked in the Workspace.
Related topics
Metering
6.2 Transport controls
The transport controls allow you to control playback within an Audio File or montage, and to
open the record window. It can be accessed via the Transport menu or the Transport toolbar.
See Command bars for more information.
The Transport menu gives access to (and shows keyboard shortcuts to) the same functions
that are available in the transport toolbar.
The Transport toolbar gives quick access to most of these functions. If the toolbar is hid-
den, select Workspace > Command bars > Transport commands. Transport functions
operate on the current Audio File.
The basic transport functions are:
Loop On/Off
- Toggles looping on/off for the currently selected Audio File or montage.
Move cursor to start of file / Move cursor to end of file
- Move the cursor to the beginning or end of the currently selected Audio File.
Move cursor to the right / Move cursor to the left
- Skip the cursor forwards or backwards within the currently selected Audio File.
Play
- Begin playback of the current Audio File.
Stop
- Stop playback of the current Audio File. A second click moves the cursor to the
beginning of the last start position. A further click returns the cursor to the start of the
file.
