36 WaveLab Elements Concepts
If you are monitoring real-time audio (playback or input), the maximum peak and loud-
ness values are displayed numerically to the right of the meter bars. Numbers in brack-
ets to the right of the Maximum Peak values indicate the number of successive clips
(0dB signal peaks). Recording levels should be set so that they only rarely clip. If the
master level is set too high, the sound quality and frequency response will be compro-
mised at high recording levels, with unwanted clipping effects. If the level is set too
low, noise levels may be high relative to the main sound being recorded.
The VU meter can be found in the Meters menu of the Audio Files and Audio Montage
Workspaces.
Related topics
Metering
4.5.2 Spectroscope
The Spectroscope shows a continuous graphical representation of the frequency spectrum,
analyzed into 60 separate frequency bands, represented as vertical bars. Peak levels are
shown as a short horizontal lines above the corresponding band, indicating recent peak/-
maximum values.
The Spectroscope can be found in the Meters menu of the Audio Files and Audio Montage
Workspaces. It can be used either as a floating window, or docked in the Workspace.
Related topics
Metering
4.5.3 Oscilloscope
The Oscilloscope offers a highly magnified view of the waveform around the playback cursor
position.
If you are analyzing a stereo file, the Oscilloscope normally shows the separate levels of
the two channels. However, if you activate the option "Show Sum and Subtraction" on the
Functions menu (or click the +/- icon), the upper half of the Oscilloscope shows the sum of
the two channels and the lower half shows the subtraction.
Making settings
By opening the Settings dialog you can adjust the display colors, and choose to activate
Auto-zoom or not. With Auto-zoom activated, the display is optimized so that the highest
level reaches the top of the display at all times. The Settings dialog can be accessed through
the Functions > Settings... menu, or by using the icon.
The Oscilloscope can be found in the Meters menu of the Audio Files and Audio Montage
Workspaces. It can be used either as a floating window, or docked in the Workspace.
