EN
This User Manual has been translated using machine translation. We have made every effort to
ensure the translation is accurate, but please note that automated translations are not perfect
and are not meant to replace human translators. The official version of the User Manual is in
English. Any differences between the translated version and the original English are not legally
binding. If you have any questions about the accuracy of the translation, please refer to the English
version, which is the official reference. More language versions are available upon request via
info@expondo.com.
Technical data
Parameter description Parameter value
Product name
Rotary evaporator
Model
SBS-RV-2000
Voltage [V] / Frequency [Hz]
230~ / 50
Power [W]
1500
Speed range [/min]
0-200
Bath volume [L]
2
Dimensions (Width x Length x Height) (mm)
650x440x690
Weight [kg]
19.3
Protection class
Purpose
The product is used to efficiently and gently remove solvents from samples through evaporation. It is widely used
in chemical, biochemical, and pharmaceutical labs.
NOTE
• Handle glassware with care; ensure it is thoroughly cleaned and dried after use.
• Always fill the water bath with water before heating. The apparatus uses electrical
heating; operating without water is strictly prohibited.
• Apply vacuum grease to all ground glass joints before connecting them.
• For costly solutions, a simulated test is recommended to confirm the unit's suitability.
• Use a thermometer to achieve precise temperature measurements.
• After use, turn off the power and unplug the device from the socket.
Assembly
1. Down-seal on Pipeline tube.
2. Apply vacuum grease on Pipeline tube and up-seal.
3. Join up-seal and lock ring, then place them onto Rotator. Insert lock pole φ3+ into lock hole φ3-.
4. Place flat seal onto lock ring.
5. Carefully tighten one flange screwed connection to join the condenser and rotator.
6. Tighten the other flange screwed connection to adapt the 29# joint with spiral onto Down-seal.
7. Turn the square nut onto spiral to release the evaporator bottle when the nut is turned back.
8. Apply vacuum grease at both joints of the feeding cock and condenser.
9. Attach PTFE tube to the feeding cock (sometimes pre-installed).
