Rev. 28.06.2022
Rev. 28.06.2022
ENEN
IX. REGULAR CONTROL OF THE MACHINE
Regularly check the machine for signs of damage. If it should be damaged, please stop using it immediately and contact your
customer service to solve the problem.
What to do in case of a problem?
Please contact your customer service and prepare following information:
• Invoice number and serial number (the latter is to be found on the technical plate on the machine).
• if relevant, a picture of the damaged, broken or defective part.
• It will be easier for your customer service clerk to determine the source of the problem if you give a detailed and
precise description of the matter.
The more detailed your information, the better customer service will be able to solve your problem rapidly and efciently!
CAUTION: Never open the machine without the authorization of your customer service. This can lead to a loss of warranty!
The machine does not contain any substances harmful to one’s health, its parts are made of metal. After withdrawal from
service, the machine must be transferred to a scrap yard. Observe the environmental protection regulations of the given
country.
1 2 3 4 5 6 7 8 10 11 12 13 14 15 16 17 18 19 20 21
22 23 24 2526
27
28 29 3031 32 33
34
35
36
37
38
39
40 41
42
43
44
45
46
47
VIII. GENERAL MACHINE DIAGRAM
1 Wheel housing 17 Plate right side 33 Nut
2 Nut 18 Bearing load ring 34 Clutch
3 Arbor 19 Spindle transmission 35 Rack
4 Wheel 20 Transmission 36 Bearing load ring
5 Hub washer 21 Bent plate 37 Lid
6 Ratchet wheel 22 Chain 38 Nut
7 Ratchet 23 Break 39 Washers
8 Ratchet arbor 24 Roller 40 Screws
9 Plate left side 25 Arbor 41 Lower clamp
10 Spring 26 Stripper 42 Wheel shaft
11 Arbor 27 Nut 43 Needle
12 Rivet 28 Hub suspension 44 Hook
13 Rivet 29 Hub arbor 45 Latch
14 Upper clamp 30 Chain gear wheel 46 Roller
15 Shaft arbor 31 Ring 47 Load chain
16 Support 32 Roller
