12345678/ 8

Afdrukken

Je bekijkt pagina 3 van 8

3

061013_v1901

2

11. Battery capacity: 6600mAh

12. Max. cleaning surface: 100 ㎡

13. Filter capacity: appr. 10m³/h

14. Filter capability: 180μm

15. Climbing slope: 15°

16. Pool water temperature: 10℃-35℃

17. Moving speed: appr. 16m/min

18. IP Grade: IPX8 (main body)

19. Charging environment temperature: 0℃-45℃

20. Max. water depth: 2.0m

21. Size: 400(L)*360（W）*270（H）mm

22. Weight: 5.5kg

23. Storage condition:

Short term (less than 1 month): -20℃-60℃，≤75%RH

Medium term (less than 3 months): -20℃-45℃，≤75%RH

Long term (more than 3 months): -20℃-20℃，≤75%RH

IV. Operation instruction

1. Precautions

a. Put into or lift out from pool with the cleaner bottom toward the wall to avoid any

possible scratch to the pool.

2

11. Battery capacity: 6600mAh

12. Max. cleaning surface: 100 ㎡

13. Filter capacity: appr. 10m³/h

14. Filter capability: 180μm

15. Climbing slope: 15°

16. Pool water temperature: 10℃-35℃

17. Moving speed: appr. 16m/min

18. IP Grade: IPX8 (main body)

19. Charging environment temperature: 0℃-45℃

20. Max. water depth: 2.0m

21. Size: 400(L)*360（W）*270（H）mm

22. Weight: 5.5kg

23. Storage condition:

Short term (less than 1 month): -20℃-60℃，≤75%RH

Medium term (less than 3 months): -20℃-45℃，≤75%RH

Long term (more than 3 months): -20℃-20℃，≤75%RH

IV. Operation instruction

1. Precautions

a. Put into or lift out from pool with the cleaner bottom toward the wall to avoid any

possible scratch to the pool.

5

a. Settings of nozzle angle and moving route

The nozzles of the cleaner are marked with angles (0°—40°).

The cleaner moves in an approximately straight line when the nozzle angle is 0°.

The cleaner moves in a more curved line at a larger angle from 0°- 40°.

b. Recommended three CYCLEs and nozzle settings

Setting One: default setting: 0

°——

30

°

, for most of pools.

Nozzle

angle

Moving

route

5

a. Settings of nozzle angle and moving route

The nozzles of the cleaner are marked with angles (0°—40°).

The cleaner moves in an approximately straight line when the nozzle angle is 0°.

The cleaner moves in a more curved line at a larger angle from 0°- 40°.

b. Recommended three CYCLEs and nozzle settings

Setting One: default setting: 0

°——

30

°

, for most of pools.

Nozzle

angle

Moving

route

5

a. Settings of nozzle angle and moving route

The nozzles of the cleaner are marked with angles (0°—40°).

The cleaner moves in an approximately straight line when the nozzle angle is 0°.

The cleaner moves in a more curved line at a larger angle from 0°- 40°.

b. Recommended three CYCLEs and nozzle settings

Setting One: default setting: 0

°——

30

°

, for most of pools.

Nozzle

angle

Moving

route

ALL

9

4.! Clean the filter tray

a.! Open the cleaner by clips

.

b.! Take off the filter tray

c.! Clean the filter tray and chassis

3

b. Install the brush before use to avoid possible dirt leaks.

c. Please ensure that top cover of the cleaner is tightly assembled with its chassis.

d. Power off the cleaner after use.

e. Do not touch the wall to avoid scratching the wall or damaging the cleaner when putting

into or lift out from pool.

f. It is necessary to stay on the water surface for 10-15 seconds until water flows out from

the cleaner to the pool before being placed on the ground.

g. Lift the handle or clips of the cleaner out from the pool.

3

b. Install the brush before use to avoid possible dirt leaks.

c. Please ensure that top cover of the cleaner is tightly assembled with its chassis.

d. Power off the cleaner after use.

e. Do not touch the wall to avoid scratching the wall or damaging the cleaner when putting

into or lift out from pool.

f. It is necessary to stay on the water surface for 10-15 seconds until water flows out from

the cleaner to the pool before being placed on the ground.

g. Lift the handle or clips of the cleaner out from the pool.

Abbildung 3 / Illustration 3

Abbildung 5 /

Illustration 5

Abbildung 4 /

Illustration 4

Abbildung 6 /

Illustration 6

Abbildung 7 /

Illustration 7

9

4.! Clean the filter tray

a.! Open the cleaner by clips

.

b.! Take off the filter tray

c.! Clean the filter tray and chassis

9

4.! Clean the filter tray

a.! Open the cleaner by clips

.

b.! Take off the filter tray

c.! Clean the filter tray and chassis

Abbildung 8 /

Illustration 8

Abbildung 9 /

Illustration 9

Abbildung 10 /

Illustration 10

9

4.! Clean the filter tray

a.! Open the cleaner by clips

.

b.! Take off the filter tray

c.! Clean the filter tray and chassis

9

4.! Clean the filter tray

a.! Open the cleaner by clips

.

b.! Take off the filter tray

c.! Clean the filter tray and chassis

Abbildung 11 /

Illustration 11

Abbildung 12 /

Illustration 12
