Je bekijkt pagina 4 van 24
Speedcleaner Evolution EX 500 | 2013_V1
Page 4 of 24
EN
Preparing your Pool
Before you assemble and install your pool cleaner, we strongly rec-
ommend you carry out the following steps to ensure your pool is
ready for cleaner to operate.
1. Make sure the chemical balance of your pool water is correct.
2. Brush your pool and let any debris settle.
3. Vacuumyour pool, using a manual vacuum cleaner.
4. Clean your pool filter, skimmer basket and pump strainer basket.
5. Close the pool main drain. ( If your pool has one.)
6. Adjust the pool return lines so the water flow is directed downward
to ensure complete cleaning of your pool. The flow of water
fromthe return line(s) can affect the performance of pool cleaner,
as it can push the cleaner away fromcertain areas, or cause it to
stay in one section of the pool. To turn the flow downward simply:
Loosen the lock ring.
Turn the eyeball, so the flow is directed downward.
Retighten the lock ring.
7. If necessary, replace the eyeball fitting with the Return Line Di-
verter supplied with your pool cleaner. To do so, simply:
Make sure the pool pump is switched off.
Unscrew the lock ring.
Replace the original eyeball with the Return Line Diverter.
Make sure the Return Line Diverter is positioned so as to direct the
flow downwards.
Check contents Picture 1
No.:
Description
Quantity
1
Cleaner complete with Footpad
1
2
Disc
1
3
Hose legths
10
4
Deflector Wheel
1
5
Hose Weight
3
6
Flow Control Valve
1
7
Control Valve Adapter
1
8
Return Line Diverter
1
9
Agile Adaptor
1
Assemble the Pool Cleaner, Image 2
Use the Deflector Wheel, Image 3
Connect Hose & Position the hose weight, Image 4
hose weight, image 5
1 > move forward
2 > right position
3 > move backwards
Connecting & using the flow control valve
The Flow Control Valve ensures your pool cleaner receives the flow
required to ensure optimum performance.
Image 6
1 hose connection
2 flow control valve
3 Adapter for flow control valve
4 press into bottom of skimmer
Imae 7
1 Hose through skimmer opening
Image 8
Position 1 = minimum flow
Position 6 = maximum flow
Before using the speedcleaner, the hoses must be filled completely
with water.
Requires a minimum filter performance of 5.500 l/h.
Troubleshooting
Problem
Solution
Pool cleaner does
not move, or slowly.
Make sure the main drain is closed.
Check the Flow Control Valve an
make sure the flow to pool cleaner
is sufficient.
Check diaphragm for war or dam-
age.
Backwash filter and empty pump strainer
basket.
Pool cleaner gets
stuck at steps or in a
corner.
Fit Deflector Wheel.
Make sure total hose length is cor-
rect.
Adjust return line eyeball fittings to use the
water flow to help guide away the steps or
corner.
Pool cleaner moves
in a repetitive, non-
ran dom pattern.
Make sure return line fittings are di-
rected down wards.
Check that hose weight position is
correct.
Make sure total hose length is correct.
Pool cleaner stays in
only one end of the
pool.
Check the return line flow and redi-
rect if necessary.
Check the total hose length and add
more hose if necessary.
Check that hose weight position is
correct.
Air bubbles an be
seen in the flow from
the return line.
Check the hose to ensure there are
no leaks.
Check the connection of the flow
Control Valve, to make sure it is
underwater at all time.
Check the pump basket lid is fitted correct-
ly, is not loose or cracked and that no o-
ring are worn or missing. If necessary,
contact your pool professional for assis-
tance.
