Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols

This manual may make reference to trademarks, registered trademarks, and other protected names and/or symbols of third-

party companies not related in any way to StarTech.com. Where they occur these references are for illustrative purposes only

and do not represent an endorsement of a product or service by StarTech.com, or an endorsement of the product(s) to which

this manual applies by the third-party company in question. StarTech.com hereby acknowledges that all trademarks, registered

trademarks, service marks, and other protected names and/or symbols contained in this manual and related documents are the

property of their respective holders.

Warranty Information

This product is backed by a two-year warranty.

For further information on product warranty terms and conditions, please refer to www.startech.com/warranty.

Limitation of Liability

In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their ocers, directors, employees or agents)

for any damages (whether direct or indirect, special, punitive, incidental, consequential, or otherwise), loss of prots, loss of

business, or any pecuniary loss, arising out of or related to the use of the product exceed the actual price paid for the product.

Some states do not allow the exclusion or limitation of incidental or consequential damages. If such laws apply, the limitations

or exclusions contained in this statement may not apply to you.

Safety Measures

• If product has an exposed circuit board, do not touch the product under power.

Mesures de sécurité

• Si l’un des circuits imprimés du produit est visible, ne pas touchez le produit lorsqu’il est sous tension.

安全対策

• 製品に露出した状態の回路基盤が含まれる場合、電源が入っている状態で製品に触らないでください。

Misure di sicurezza

• Se il prodotto p2-ha un circuito stampato visibile, non toccare il prodotto quando è acceso.

Säkerhetsåtgärder

• Rör aldrig vid enheter med oskyddade kretskort när strömmen är påslagen.

FR: fr.startech.com

DE: de.startech.com

ES: es.startech.com

NL: nl.startech.com

IT: it.startech.com

JP: jp.startech.com

StarTech.com Ltd.

45 Artisans Cres

London, Ontario

N5V 5E9

Canada

StarTech.com Ltd.

Unit B, Pinnacle 15

Gowerton Rd,

Brackmills

Northampton

NN4 7BW

United Kingdom

StarTech.com LLP

2500 Creekside

Parkwy

Lockbourne, Ohio

43137

U.S.A.

Mount the Power Strip to a Surface (Temporary Mounting Only)

1. Locate a suitable surface to mount the Power Strip.

Note: The surface structure should be capable of supporting at least four times the

weight of the mounted equipment.

2. Position the included Mounting Template onto the surface in the desired mounting

location, and tape it into place using Painters Tape.

4. Peel o the Painter’s Tape and remove the Mounting Template from the surface to

expose the newly created mounting holes. Use a Phillips® Head Screwdriver to secure

one of the provided Mounting Screws into each of the Mounting holes.

Note: When securing the Mounting Screws into the surface, ensure that the

2.4mm spacer portion of each screw is left exposed.

3. Using a Drill with a 9/64 in. Drill-Bit, carefully create pilot holes by drilling through

the Mounting Template and into the surface at each of the mounting hole locations

identied on the template.

5. Position the Key-Hole Mounting Points, located on the Power Strip, over the

newly secured Mounting Screws, and slide the 4-Outlet Power Strip downward.

The Power Strip is now mounted to a surface.

Caution: The mounting feature on this Power Strip is intended for temporary

installation only.

Isolated Filter Banks

The outlets on this Power Strip are arranged in isolated lter banks (2-outlets per

bank). Isolated lter banks prevent EMI and RFI noise from interacting between

equipment that’s connected to separate banks, providing additional protection.

See the arrangement of isolated lter banks below, based upon product model:

4N515S8-POWER-STRIP

6N515S8-POWER-STRIP

8N515S12-POWER-STRIP
