Quick-Start Guide

Feature Function

1 Power Outlets x 6

• Right Angled NEMA 5-15R receptacle. Rated for 125V AC, 15 Amps

• Supplies AC Power to devices with NEMA 5-15P plugs

Circuit Breaker Manual Reset

Button

• Restores Power by resetting the Circuit Breaker when tripped

Power Switch with

Safeguard

• Turns the Power Delivery Unit ON or OFF

4-Way Mounting Brackets

Mounting Holes

• Enables mounting of the included 4-Way Mounting Brackets

Note: The 4-Way Mounting Brackets are pre-installed

4-Way Mounting Bracket

Depth Adjustment Slots

• Enable fastening the 4-Way Mounting Brackets to the PDU and adjusting the PDU

Mounting Depth

4-Way Mounting Bracket

Rack Mounting Holes

• Enables fastening of the PDU to a Server Rack or Cabinet Mounting Posts

4-Way Mounting Bracket

Keyhole

• Enables fastening of the PDU in dierent orientations

8 Grounding Point

• Attach a Grounding Wire (not included) to an Earth Ground Connection

Note: A Grounding Wire is typically Green or Green with a Yellow stripe and should be

at least 18 AWG

9 Built-in Power Cable

• NEMA 5-15P plug. Rated for 125V AC, 15 Amps

• Connects to a 125V AC Power Source via a NEMA 5-15R receptacle

10 Power Outlets x 6

• Right Angled NEMA 5-15R receptacle. Rated for 125V AC, 15 Amps

• Supplies AC Power to devices with NEMA 5-15P plugs

Package Contents

• PDU Unit x 1 (A)

• 4-Way Mounting Brackets x 2 (Pre-Installed) (B)

• M5x12mm Rack Screws x 4 (C)

• M5 Cage Nuts x 4 (D)

• Quick-Start Guide x 1

Requirements

For the latest manuals, product information, technical specications, and declarations of conformance, please visit:

www.StarTech.com/1215B8H-RACK-PDU-RA

• Phillips head screwdriver (PH1) for M3 screws and PH2 for M5 Screws

• Cage nut tool (optional)

Warnings!

• StarTech.com Ltd. is not responsible for any property damage and/or personal injury resulting from the installation

procedures outlined in this technical document

• Read the entire Quick-Start Guide and ensure the instructions are fully understood before using this product

• Refer to the manufacturer of the Server Rack to determine the mounting hole type and size

• If the Server Rack Mounting Posts have M5 threaded holes, the included M5x12mm Rack Screws can be installed without

Cage Nuts. Use the manufacturer-recommended Screws if they dier from the ones included

• Never operate this product if parts are missing or damaged

• Do not touch the product under power if the product has an exposed printed circuit board or electrical wire

• If the connected equipment overdraws excessive current for more than a few seconds, the Circuit Breaker in the Power

Delivery Unit will trip to help prevent potential equipment damage. Inspect the connected load and disconnect any

non-essential or malfunctioning devices as necessary. Allow the Power Delivery Unit to cool down for at least 60 seconds

before pressing the Manual Reset Button to restore functionality.

• Never insert foreign objects into the PDU outlets. Doing so may result in electric shock, re, serious injury, or irreparable

equipment damage. The outlets are designed exclusively for use with compatible power plugs. Always follow the

manufacturer’s instructions and applicable safety standards.

Note: This unit is only to be used inside racks within computer, telecommunications, and cloud data center rooms.
