GB - 15
Product: Vacuum cleaner for wet
and dry applications
Type:
GS
Read the operating manual carefully before starting to use the
vacuum cleaner. It provides important instructions for the operation,
safety, care and maintenance. Keep the operating manual in a safe
place and, in case you sell the unit, hand it on to the next owner.
The manufacturer reserves the right to carry out modications to
the design and equipment.
Any other work not covered by this operating manual must not be
carried out.
THIS MACHINE IS PERFECT FOR VARIOUS USES, FOR
EXAMPLE IN HOTELS, SCHOOLS, HOSPITALS, FACTORIES,
SHOPS AND LIVING QUARTERS.
1 Before use
▶ When unpacking, check that the delivery is complete and that
there is no transport damage.
▶ Before using, the operators should be provided with information,
instructions and training for the use of the vacuum cleaner
and the substances that it is to be used for, including the safe
procedure for the removal of the gathered material.
2 OPERATING INSTRUCTION
- Insert the cloth lter in the tank (Fig. 1)
- Assembly the head on tank and block it by hooks (Fig. 3)
- Connect the exible hose into the inlet (Fig. 4)
- Connect the wand and the extensions to other side of exible
hose (Fig. 5)
- Select the most suitable accessory (Fig. 6)
- Connect the plug to power socket then switch on the equipment
(Fig. 7)
- Example of use of at lance (Fig. 8)
- Example of use of round brush (Fig. 9)
- Example of use of brush for oor cleaning (Fig. 9)
- If a paper bag is provided, insert it in the tank on the deector
(Fig. 11)
3 LIQUID SUCTION / OPERATING INSTRUCTION
- Remove the cloth lter bag (Fig. 2)
- Assembly the head on tank and block it by hooks (Fig. 3)
- Connect the exible hose to the inlet (Fig. 4)
- Connect the extension to other side of exible hose (Fig. 5)
- Connect the wet tool (Fig. 6)
- Connect the plug to power socket then switch on the equipment
(Fig.7)
- Example of use of wet tool (Fig. 10)
4 MAINTENANCE
6. Always remove the plug from the current socket before
undertaking any type of intervention on the apparatus or if it is left
unattended or within children or people’s reach not quite conscious
of their own actions.
7. Regularly control the feeding cable looking for damages, cracks
or ageing. Substitute the cable before using it further.
8. If the feeding cable is damaged it must be substituted by the ma
-
nufacturer or by its after sales service or in any case by a similarly
qualied person, thus preventing any possible risk.
9. When using extension electric wires ensure that they are lying on
dry surfaces and protected against possible water jets.
10. Specialized personnel must always carry out maintenance and
repairs; any damaged part must be substituted with original spare
parts.
ATTENTION: it is forbidden to carry out changes to the apparatus.
Tampering could cause res and damages even lethal to the user
and the forfeiture of the guarantee.
The manufacturer declines any responsibility for damages caused
to people or things due to non-compliance with these instructions or
if the apparatus is unreasonably used.
5 Technical data.
Appliance version GS 2078 GS 3078
Voltage 220 - 240 V~ 220 - 240 V~
Frequency 50/60 Hz~ 50/60 Hz
Rated capacity 2400 W 3600 W
Typical sound level
(acc. to DIN EN 60704-1)
77 db(A) 79 db(A)
Weight 24 kg 26 kg
6 Technical testing
A technical examination must be carried out at least once a year
by a trained person: check the lter for damage, ensure that the
vacuum cleaner is air-tight and check that the monitoring equip-
ment functions correctly.
We declare, with exclusive responsibility, that this
product complies with the EU Directive and the rel-
evant standards: Machinery Directive 2006/42/EU
with modications, EMC Directive 2014/30/EU with
modications. 0
Original operatin instructions in German
