NEVER LEAVE HEATER UNATTENDED WHILE CONNECTED TO A POWER SOURCE
5,6.2)(/(&75,&6+2&.',6&211(&7)52032:(5%()25(0$,17(1$1&(
WARNING
Plug Replacement
NOTE: This section only applies to heaters sold or used in Great Britain.
This appliance is supplied with a BS1363 3 pin
SOXJ¿WWHGZLWKDIXVH6KRXOGWKHIXVHUHTXLUH
replacement, it must be replaced with a fuse
with the proper amp rating. (see Technical
6SHFL¿FDWLRQVSDJHDQGDSSURYHGWR%6
In the event the mains plug has to be removed/
replaced for any reason, please note:
IMPORTANT: The wires in the mains lead are
colored in accordance with the following code:
Blue – Neutral Brown – Live
Green/Yellow – Earth
As the colors of the wires in the mains lead of this
appliance may not correspond with the colored
markings identifying the terminals in your plug,
proceed as follows:
The blue wire must be connected to the terminal
marked with an N or colored black. The brown
wire must be connected to the terminal marked
with an L or colored red. The green/ yellow wire
must be connected to the earthing terminal which
is marked with an E or with the earth symbol.
127(,IDPRXOGHGSOXJLV¿WWHGDQGKDVWR
be removed take great care in disposing of the
plug and severed cable, it must be destroyed to
prevent engaging into a socket.
1HYHUFRQQHFWOLYHRUQHXWUDO
wires to the earth terminal of
the plug.
WARNING
GREEN / YELLOW
Earth
BROWN
Live
FUSE
13 Amps
CORD CLAMP
BLUE
Neutral
Plug Replacement Wiring Diagram
Figure 3
19
