GX2200
6.5.1 Internal GPS (DSC Output) to Chart Plotter
4800 Baud Connections
GPS Chart Plotter
PA Speaker
External Speaker
Shield
Shield
Red
White
Plotter Connection
Radio Wires
Gray: NMEA OUT
( )
Brown: NMEA OUT
( )
Yellow: NMEA-HS OUT
( )
White: NMEA-HS OUT
( )
Blue: NMEA IN
( )
No Connection
No Connection
NMEA IN
( )
NMEA IN-HS
( )
NMEA IN
( )
NMEA IN-HS
( )
Green: NMEA IN
( )
Wire Color/Description Connection Examples
WHITE-ExternalSpeaker
(
+
)
Positivewireofexternal4Ohmaudiospeaker
SHIELD-ExternalSpeaker
(–)
Negativewireofexternal4Ohmaudiospeaker
RED-PASpeaker
(
+
)
Positivewireofexternal4OhmPAspeaker(horn)
SHIELD-PASpeaker
(–)
Negativewireofexternal4OhmPAspeaker(horn)
BLUE-NMEAGPSInput(+) Noconnection
GREEN-NMEAGPSInput(–) Noconnection
GRAY-NMEADSCOutput(+) NMEA(+)inputofGPS*
1
BROWN-NMEADSCOutput(–) NMEA(–)inputofGPS*
1
YELLOW-AISDataOutput(+) NMEA-HS(+)inputofAISreceiver*
2
WHITE-AISDataOutput(–) NMEA-HS(–)inputofAISreceiver*
2
*1: 4800baud
*2: 38400baud
Note: Some GPS chart plotters have a single wire for NMEAsignal ground. In such acase
connect the NMEA input (–) to the GPS chart plotter’s single NMEA signal ground wire, and
leavetheNMEAoutput(–)open.IncasetheassignmentofpowersupplyandgroundofaGPS
chartplottertobeusedisdifferentfromthatoftheradio,connectthesignalgroundwireofthe
GPSchartplottertothegroundterminal(GND)ontherearpaneloftheradio.
