HX350S Owner’s Manual page 21
7 SPECIFICATIONS
Performance specifications are nominal, unless otherwise indicated, and
are subject to change without notice.
7.1 GENERAL
Frequency Range ............................................... 156.025 to 163.275 MHz
Channels ................................. All currently allocated USA, Canadian and
International channels, plus 10 weather channels.
RF Power Output with
CNB350/CNB350AS
Battery........ 5.0 W
(high)
1.0 W
(low)
Operating Voltage ......................................................................... 7.2 VDC
Current Drain:
Standby ..................................................................................... 40 mA
Receive ................................................................................... 200 mA
Transmit ................................... 1.8 A (high power), 0.7 A (low power)
Dimensions...............................................5.51” H x 2.17” W x 1.50” D
(140.0 mm x 55 mm x 38 mm)
Weight ........................................................................1.0 Ib. (0.45 Kg)
FCC Type Acceptance Number ........................................... APV0697
Industry Canada Type Approval Number ........................ 363822196A
Battery Life(5% TX, 5% RX, 90% Standby) ................... 10 hrs. (high)
15 hrs. (low)
7.2 TRANSMITTER
Conducted Spurious Emissions ..........................65 dB (high); 55 dB (low)
Audio Response........................ within +2/-8 of 6 dB/octave pre-emphasis
characteristic from 300 Hz to 3000 Hz
AF Harmonic Distortion ........................................................................ 3 %
Hum and Noise ................................................................................. 37 dB
Frequency Stability (-20° to +50°C) ....................................... +/- 0.0005 %
7.3 RECEIVER
Sensitivity:
20 dB Quieting ........................................................................ 0.35 µV
12 dB SINAD ........................................................................... 0.30 µV
Squelch Sensitivity (Threshold) ..................................................... 0.20 µV
Modulation Acceptance Bandwidth ........................................... +/- 4.5 kHz
Selectivity:
Spurious and Image Rejection ................................................... 60 dB
Intermodulation Rejection .......................................................... 60 dB
Channel Spacing ...................................................................... 25 kHz
