Page 1
QUICK REFERENCE
PTT (Push-To-Talk): Activates the transmitter when pressed.
SQL: Press to display the SQL level setting screen, then press the [▲] /
[►] key to squelch or press the [▼] / [◄] to un-squelch the radio.
Press and hold to open the squelch. Press the key to resume normal.
Strobe Light: Glows the Strobe Light continuously by pressing the [STRB]
soft key.
MENU/SET:
Press to access MENU. Press and hold to enter SETUP Mode.
VOL− / +VOL: Press to adjust the speaker audio volume.
16/S:
Press to recall channel 16. Press and hold to recall the sub channel.
Soft keys: These three programmable keys can be customized through
the setup menu mode. By pressing one of these keys briey, display the
key functions at the bottom of the display.
MIC: Speak slowly and clearly into the MIC aperture having it about 1/2 to
1 inch (1.2 to 2.5 cm) away from your mouth while pressing the PTT key.
◄/►: Press to toggle the on-screen menus to right/left.
▼/▲: Press to change the operating channel.
CLR/ : Press to cancel a function or menu selection.
Press and hold to lock and unlock the keypad.
: Press and hold to turn the transceiver ON/OFF.
