Page 1
QUICK REFERENCE
HX210
①
②
③
④
⑤
⑥
⑧
⑨
⑩
⑪
⑦
⑤
PTT (Push-To-Talk): Activates the transmitter when pressed.
SQL: Press to display the SQL level setting screen, then press the [▲]
key to squelch or press the [▼] to un-squelch the radio.
MIC: Speak slowly and clearly into the MIC
aperture
having it about 1/2 to
1 inch (1.2 to 2.5 cm) away from your mouth while pressing the PTT key.
MENU/SET:
Press to access MENU. Press and hold to enter SETUP Mode.
VOL− / VOL+: Press to adjust the speaker audio volume.
16/S:
Press to recall channel 16. Press and hold to recall the sub channel.
Soft keys: These three programmable keys can be customized through
the setup menu mode. By pressing one of these keys briey, display the
key functions at the bottom of the display.
Strobe Light: Glows the Strobe Light continuously by pressing the
[STROBE] soft key.
◄/►: Press to toggle the on-screen menus to right/left.
▼/▲: Press to change the operating channel.
CLR/ : Press to cancel a function or menu selection. Press and hold
to lock and unlock the keypad.
: Press and hold to turn the transceiver ON/OFF.
