Page 60 GPS chartplotters
can be changed. The picture below shows the Chart Page with 1 Line Large selected and
a Popup window with many selections.
1. To change a data window field, press and hold [MENU] until the field is highlighted.
2. Move the ShuttlePoint knob to the desired data field and press [ENTER]. The popup
window will be shown.
3. Move the ShuttlePoint knob up or down to choose the desired setting and press
[ENTER] to select and press [CLEAR] to store and exit the editing mode.
Figure 10.0.5 - Customize the Data Windows
NOTE
Data window field on the NAVIGATION, HIGHWAY, GPS STATUS, and NMEA pages may be
customized in the above manner.
10.1 CUSTOMIZING CHART SETTINGS
1. Press [MENU] and move the Shuttlepoint knob to highlight SETUP and press [ENTER].
2. Move the ShuttlePoint knob to
CHART SETUP and press [ENTER].
3. Move the Shuttlepoint knob to
CUSTOMIZE CHART and press [ENTER].
4. Move the ShuttlePoint knob up or down to select
MARINE SETTINGS, DEPTH
SETTINGS, LAND SETTINGS or CHART SETTINGS and press [ENTER]. See the
above sections for details on selections within each of the settings.
10.2 NAVIGATION PAGE
This page is useful to show information when heading to a destination. The default page is
shown with a Compass Rose, however this can be customized to show a Compass Tape.
1. To change to show the COMPASS TAPE, select the Chart Page, press [MENU] and
move the ShuttlePoint knob to select
SETUP and press [ENTER].
2. Move the ShuttlePoint knob to select
WINDOW SETUP and press [ENTER].
3. Move the ShuttlePoint to
NAVIGATION PAGE and press [ENTER]
4. Move the ShuttlePoint up or down to select
COMPASS TAPE and press [ENTER].
Press [CLEAR] or move the Shuttlpoint knob to the right until the Chart Page is shown.
