GPS Chart 160/170C Page 9
1. GENERAL INFORMATION
NOTE
Throughout this manual, the labelled keys are shown in capital letters enclosed
between apostropies, for example the
MENU
key is indicated as 'MENU'. The label
of the software keys (called soft keys for short) are shown in small capitals letters
enclosed between apostropies, for example 'C
HART'. Menu operations are in bold
characters listed by key sequence with the menu item names enclosed between
quotation marks, for example 'MENU' + "ADVANCED SETUP" + 'ENTER' +
"INPUT/OUTPUT" + 'ENTER' means: press the
MENU
key, using the
ShuttlePoint
knob to select the Advanced Setup menu, press the
ENTER
key, using the
ShuttlePoint
knob to select the Input/Output menu and then press the
ENTER
key.
Terms and functions underlined, for example Target, are explained in the Section 8.
1.1 INTRODUCTION
The chartplotter is a computer specifically designed for nautical use but, more
precisely, to ease and speed up all calculations, which so far have been done
manually. The chartplotter displays the current position, the speed, and the heading
of the boat and its Track. The user information like Waypoints, Marks and Tracks can
be stored on a optional User C-CARD (for backup) and can be recalled at any time.
On the screen are shown navigation data and cartographic information obtained from
electronic charts
.
1.2 IF YOU NEED ASSISTANCE
If your chartplotter does not operate properly, go to the System Test on Section 7.1.
Most common operating difficulties can be diagnosed using these tests. If you still
need assistance, call STANDARD HORIZON Product Support or your local Dealer,
reporting the Software System Information
, Cartography Information and
Storage Capacity
available in the About page.
Select About Page: 'MENU' + "About..." + 'ENTER'
