Page 12 GPS Chart 160/170C
3. CONTROLS AND INDICATORS
NOTE
This Section defines each control of the chartplotter. For detailed operating instructions,
refer to Section 8. Refer to Figure 3.1 for the location of the following keys and connections.
3.1 CONTROLS AND CONNECTIONS
The chartplotter is controlled by using 15 keys: 10 labelled keys are dedicated to specific
functions; the other 5 keys (hereinafter named soft keys) have different functions associated
depending on the software: their labels are shown on the screen immediately above the keys
(the user can customize the function associated, see Section 3.1.1).There is also a
ShuttlePoint
knob to move a cursor across the screen.
As you press a key, a single audio beep
confirms the key action; every time the key pressed is not valid, three rapid beeps sound
indicates that no response is available.
ENTER
MARK
ZOOM
OUT
ROUTE
PWR
MENU
CLEAR
GOTO
MOB
ZOOM
IN
1
2
3
4
5
6
7
8
9
10
11
13
12
14
Figure 3.1 - The chartplotter
