Rev. 14.01.2019 Rev. 14.01.2019
EN
11. Open the housing under no circumstances.
12. WARNING - FIRE RISK! If the magnifying glass is used incorrectly, it may focus a beam of light onto a
small area, which in turn will generate a very high temperature!
13. Do not look directly at the light source with the lamp switched on. Do not use the magnifying glass to
look at other light sources (e.g. LED diodes, laser, etc.) - this may damage your eyesight!
14. Do not leave the device or its packaging unsupervised.
TECHNISCHE DETAILS
Product name Magnifying Lamp Magnifying Lamp Magnifying Lamp
Model S-LP-2B S-LP-3S S-LP-4G
Rated voltage [V] /
Frequency [Hz]
230~V±10% / 50Hz 230~V±10% / 50Hz 230~V±10% / 50Hz
Light source LED diodes – 40 pcs LED diodes – 40 pcs LED diodes – 40 pcs
Magnifying glass diameter
[mm]
90 90 90
Magnifying glass 5x / 10x 5x / 10x 5x / 10x
Power [W] 1 1 1
Dimensions of base
(L x W) mm
125x200 125x200 125x200
Useful luminous ux [lm] 44.74 44.74 44.74
Reference power [W] 1.426 1.426 1.426
Power corrected [W] 0.92 0.92 0.92
Energy efciency index
(EEI)
0.114 0.114 0.114
Energy efciency class A++ A++ A++
Protection class I I I
Protection rating IP IP20 IP20 IP20
SCOPE OF APPLICATION
The magnifying lamp is designed for direct observation of small items from a short distance.
The user is liable for any damage resulting from non-intended use of the device!
BEFORE FIRST USE
Upon receipt of the goods, check the packaging for integrity and open it. If the packaging is damaged,
please contact your transport company and distributor within 3 days, and document the damages as
detailed as possible. Do not turn the package upside down! When transporting the package, please
ensure that it is kept horizontal and stable.
DISPOSING OF PACKAGING
Please keep all packaging materials (cardboard, plastic tapes and Styrofoam), so that in case of a problem,
the device can be sent back to the service centre in accurate condition.
INSTALLING THE APPLIANCE
Appliance location
8
DEEN
PRINCIPLE OF OPERATION
1
2
3
4
5
6
7
1. LED lighting
2. opening magnifying glass cover
3. adjustable arm
4. ON/OFF switch
5. magnetic elements(only for S-LP 3S)
6. base
7. power cable
ASSEMBLY / USE OF THE DEVICE’S ELEMENTS:
Ensure the power cable does not constitute an obstacle for those in the vicinity. Connect the plug to an
electricity socket. Turn the lamp on using the main switch in the base of the lamp.
Only for S-LP 3S: There are two magnetic elements on the bottom base of the lamp which may be used
to keep items in place.
TRANSPORTATION AND STORAGE
Shaking, crashing and turning upside down of the device should be prevented when transporting it. Store
it in a properly ventilated location with dry air and without any corrosive gas.
CLEANING AND MAINTENANCE
• Disconnect from electricity when cleaning equipment.
• Use cleaner without corrosive substances to clean surface.
• Dry all parts well after cleaning before the device is used again.
• Store the unit in a dry, cool location, free from moisture and direct exposure to sunlight.
REGULAR CONTROL OF THE DEVICE
Regularly control whether the device is damaged. If it should be damaged, please stop using it immediately
and contact your customer service to solve the problem.
What to do in case of a problem?
Please contact your customer service and prepare the following information:
• Invoice number and serial number (the latter is to be found on the technical plate on the device).
• If relevant, a picture of the damaged, broken or defective part.
• It will be easier for your customer service clerk to determine the source of the problem if you give a
detailed and precise description of the matter. Avoid ambiguous formulations like “the device does not
heat”, which may mean either that it does not heat enough or that it does not heat at all. The more
detailed your information, the better the customer service will be able to solve your problem rapidly
and efciently!
CAUTION: Never open the device without the authorization of your customer service. This can lead to
a loss of warranty!
9
The temperature of environment must not be higher than 45 °C and the relative humidity should be less
than 85%. Ensure good ventilation in the room in which the device is used. The distance from any wall
of the device should be not less than 10 cm. Operate the device on at, stable, clean, refractory and dry
surfaces out of the reach of children and people with mental disabilities. Install the device making sure
that constant access to the main plug is ensured. The power cord connected to the appliance must be
properly grounded and correspond to the technical details. Before rst use, remove all elements and
clean them along with the entire device.
