7.2.2 DMX mode

This setting is only relevant if the device is controlled via a DMX controller.

1. Press [Mode] to activate the main menu.

2. Press [Mode] or [Up]/[Down] until the display shows ‘DMX’ .

3. Press [Setup] to conrm the selection.

4. Press [Up]/[Down] until the display shows ‘Channels’ .

5. Press [Setup] to conrm the selection.

6. Press [Up]/[Down] to select the desired DMX mode.

The following DMX modes are available:

Menu level 3 Function

‘10-CH’ 10-channel mode

‘19-CH’ 19-channel mode

7. When the display shows the required value, press [Setup] to conrm the selec‐

tion.

7.2.3 Manual control

This setting is only relevant if the device is not controlled via a DMX controller and

not working as a slave in a master/slave conguration. This operating mode can be

used to set the pan, tilt, colours and strobe.

1. Press [Mode] to activate the main menu.

2. Press [Mode] or [Up]/[Down] until the display shows ‘Control’ .

3. Press [Setup] to conrm the selection.

4. Press [Up]/[Down] to select the required submenu or value.

The following submenus are available:

Menu level 2 Menu level 3 Function

‘Pan’ ‘000’ … ‘255’ Adjusts the rotation angle.

‘Tilt’ ‘000’ … ‘255’ Adjusts the tilt angle.

‘Red1’ ‘000’ … ‘255’ Adjusts the intensity for red (LED 1).

‘Green1’ ‘000’ … ‘255’ Adjusts the intensity for green (LED 1).

‘Blue1’ ‘000’ … ‘255’ Adjusts the intensity for blue (LED 1).

‘White1’ ‘000’ …‘255’ Adjusts the intensity for white (LED 1).

‘Red2’ ‘000’ … ‘255’ Adjusts the intensity for red (LED 2).

‘Green2’ ‘000’ … ‘255’ Adjusts the intensity for green (LED 2).

‘Blue2’ ‘000’ … ‘255’ Adjusts the intensity for blue (LED 2).

‘White2’ ‘000’ …‘255’ Adjusts the intensity for white (LED 2).

5. When the display shows the required value, press [Setup] to conrm the selec‐

tion.

Operating

SonicPulse MH Wash 1208

Moving Head
