1 Locking screw for the mounting bracket

2 Mounting bracket

3 [T1A/250V] | Fuse holder

4 [Power In] | Lockable input socket (Power Twist) for connection to mains power

5 [DMX In] | DMX input, designed as XLR panel plug, 3-pin

6 Built-in microphone for sound control

7 Display

8 [Mode] | Activates the main menu and toggles between menu items

9 [Setup] | Selects an option of the respective operating mode

10 [Up] | Navigates upwards in a menu list, increases the displayed value by one

11 [Down] | Navigates downwards in a menu list, reduces the displayed value by one

12 [DMX Out] | DMX output, designed as XLR panel socket, 3-pin

13 [Power Out] | Lockable output socket (Power Twist) for powering a connected device

Connections and controls

SonicPulse LED Bar 05, SonicPulse LED Bar 10
