PowerI n
T2A/ 250V
DMX In
DMX Ou t
Foot switch I nput
Mode Setu p
Up
Down
100- 240V~ 50/60 Hz
PUSH
FUSE
ScanSphere 300
Power Out
100-240V
~
50/60Hz
Max.:3A
Power Out
100-240V
~
50/60Hz
Max.:3A
Item no:580814
Voltage: 100-240V
~
50/60Hz
Wa!: 236W
$ *) &( ' $%
ö ö#
1 [Power Out] | Lockable output socket (Power Twist) for powering a connected device
2 [Power In] | Lockable input socket (Power Twist) for connection to mains power
3 Mounting bracket with locking screw
4 [T2A/250V] | Fuse holder
5 [DMX In] | DMX input, designed as XLR panel plug, 3-pin
6 [DMX Out] | DMX output, designed as XLR panel socket, 3-pin
7 [Footswitch Input] | 6.35-mm jack socket for connecting the foot switch unit
8 Built-in microphone for sound control
9 Display with function buttons
[Mode] | Activates the main menu. Closes an open submenu without saving the changes.
[Setup] | Selects an option of the respective operating mode, conrms the set value.
[Up] | Toggles between menu items, increases the displayed value by one.
[Down] | Toggles between menu items, decreases the displayed value by one.
Rear panel
Connections and controls
ScanSphere 300
13
