This setting is only relevant if the device is controlled via a DMX controller.

1. Press [MENU] to open the main menu.

2. Use [UP] or [DOWN] to select the ‘DMX’ menu option and conrm with [ENTER].

3. Use [UP] or [DOWN] to assign a DMX address in the range from ‘A001’ … ‘A511’ to the

device (highest possible DMX address in 2-channel operation) and conrm with [ENTER].

The following table shows the assignment of the two DMX channels.

Channel Function Value

1 Dimmer function 0% … 100%

2 Strobe eect 0% … 100%

4. To return to the previous menu level without changes, press [MENU].

This setting can only be activated if the device is operating in stand-alone mode or as the

master in a master/slave conguration and if the device is not controlled via a DMX controller.

1. Press [MENU] to open the main menu.

2. Use [UP] or [DOWN] to select the ‘Strobe’ menu option and conrm with [ENTER].

3. Use [UP] or [DOWN] to specify the ash frequency for the strobe eect in a range from

‘ST00’ … ‘ST99’ (o, fast … slow) and conrm with [ENTER].

4. To return to the previous menu level without changes, press [MENU].

“DMX” mode

“Strobe” mode

Operating

RevueLED 120 COB 3200K DMX

LED Spotlight
