1 Display | Displays the main menu and device information.

2 [HEAT] | Lights up while the device is heating up.

3 [FAULT] | Lights up when there is a malfunction.

4 [DMX] | Lights up when a DMX signal is received.

5 [READY] | Flashes while the device is heating up. Lights up when the device has heated up and is operational.

6 [Power OUT (6A)] | Lockable Power Twist TR1 output socket for the power supply for further devices

7 [POWER IN (12A)] | Lockable Power Twist TR1 input socket for the power supply

8 Function buttons

| Selects a higher menu item or increases the displayed value by one.

| No function

| Selects a lower menu item or decreases the displayed value by one.

| Returns to the previous menu level

[OK] | Calls up the main menu and selects an option or conrms the set value.

9 [F6.3A H250V] | Fuse holder

10 [POWER ON/OFF] | Main switch

11 [DMX IN] | DMX input, 3-pin

12 [DMX OUT] | DMX output, 3-pin

Connections and controls

Prometheus Spark 1

Spark Eect
