5 Starting up

Create all connections while the device is o. Use the shortest possible high-quality cables for

all connections. Take care when running the cables to prevent tripping hazards.

NOTICE!

Data transfer errors due to improper wiring!

If the DMX connections are wired incorrectly, this can cause errors during the data

transfer.

Do not connect the DMX input and output to audio devices, e.g. mixers or ampli‐

ers.

Use special DMX cables for the wiring instead of normal microphone cables.

Connect the DMX input of the device to the DMX output of a DMX controller or another DMX

device. Connect the output of the rst DMX device to the input of the second one and so on,

to form a series connection. Make sure that the output of the last DMX device in the chain is

terminated by a resistor (110 Ω, ¼ W).

Connections in “DMX” mode

Starting up

Prometheus Spark 1

Spark Eect
