1 Two-piece bracket for hanging or oor setup

2 Locking screws for the two-piece bracket

3 Display

4 [MODE] | activates the main menu, toggles between the menu items or closes a submenu

[SET] | ppens a submenu or conrms a value

[UP] | increases the displayed value by one

[DOWN] | decreases the displayed value by one

5 Safety cable eyelet

6 Pressure compensation element

7 [DMX In] | DMX input, designed as 3-pin XLR panel plug (IP65)

8 [DMX Out] | DMX output, designed as 3-pin XLR panel socket (IP65)

9 [Power In] | input socket (Power Twist TR1) for powering the device

10 [Power Out] | output socket (Power Twist TR1) for powering further devices

Connections and controls

Outdoor Stage Par Tri TR1

LED PAR
