Press [Mode] repeatedly until the display shows ‘d.xxx’ . Now you can set the number of the

rst DMX channel to be used by the device (DMX address). Use [Up] and [Down] to select a

value between 1 and 512 (the display shows ‘d.001’ … ‘d.510’ ).

Make sure that this number matches the conguration of your DMX controller. The following

table shows the highest possible DMX address for the various DMX modes.

Mode Highest possible DMX address

1-channel 512

4-channel 509

5-channel 508

7-channel 506

Conrm with [Setup]. With [Up] and [Down] you can now select one of the following DMX oper‐

ating modes:

n ‘1-ch’ (one channel)

n ‘4-ch’

(four channels)

n ‘5-ch’ (ve channels)

n ‘7-ch’

(seven channels)

This setting is only relevant when the device is controlled via DMX. When the display shows

the desired value press [Setup] to conrm the selection and return to the parent menu.

DMX mode

Operating
