In the master-slave conguration, you can interconnect four devices of the same type to one

large matrix with 10 × 10 LEDs. The eects then use this device combination in common.

Press [Mode] repeatedly until the display shows ‘SLAv’ .

Press [Setup]. With [Up] and [Down] you can now set the position at which the particular device

is located within the equipment combination. The gure alongside shows the possible values

and their meaning. Unit ‘S.1-1’ works as Master.

Press [Mode] repeatedly until the display shows ‘Soud’ . This activates a sound controlled auto‐

matic show.

Press [Setup] and use [Up] and [Down] to adjust the sensitivity for the sound control in a range

from ‘SU.00’ (low sensitivity) to ‘SU.31’ (high sensitivity).

Press [Mode] repeatedly until the display shows ‘ChAr’ . Press [Setup]. With [Up] and [Down] you

can now select between the display of letters (display shows ‘Lett’

) and the display of numbers

(display shows ‘nUbe’ ). Press again [Setup] and use [Up] and [Down] to choose the letter or

number to be displayed.

Operating mode ‘Slave’

S.1-1 S.1-2

S.2-1 S.2-2

Sound control

Display of letters and numbers

Operating

LED Matrix Blinder 5×5 MKII

Blinder
