1 Display
2 Function buttons
[MENU] | Selects an option of the respective operating mode, conrms the set value.
[UP] | Increases the displayed value by one.
[DOWN] | Decreases the displayed value by one.
[ENTER] | Activates the main menu and toggles between menu items. Closes an open submenu.
3 [POWER IN] | Lockable input socket (Power Twist) for the power supply of the device
4 [POWER OUT] | Lockable output socket (Power Twist) for powering further devices (max. output current: 5 A)
5 [DMX OUT] | DMX output, designed as 5-pin XLR panel coupler
6 [DMX IN] | DMX input, designed as 5-pin XLR panel plug
7 Locking screws for the mounting bracket
8 Mounting bracket
Connections and controls
20
DuoBlind 200 WW
