1 [ON/OFF]

Mains switch. Turns the device on and o.

2 [DMX In]

DMX input, designed as 3-pin XLR chassis-mounted plug

3 [DMX Thru]

Passive DMX output (XLR chassis socket, 3-pin) for looping the signal to a connected device. This output is only

active, if the [Pass Thru / Terminated] switch is not pressed.

4 [Out 1]…[Out 8]

8 × active DMX outputs (XLR chassis sockets, 3-pin) to buer, amplify and distribute the signal to other DMX chains,

three- and ve-pin type with control LEDs for the signals on the DMX data lines of the DMX outputs. The red LED

indicates the operational readiness of the DMX outputs. The green LED lights up when a DMX controller is connected

and a signal is transmitted on the data line.

Connections and controls

DMX Splitter 8 USB 3 pin, USB 5 pin

DMX Splitter
