12 [ILDA THROUGH] | 25-pin ILDA output socket for looping through the ILDA signal to other devices

13 [ILDA INPUT] | 25-pin ILDA input socket

14 IEC chassis plug for the mains cable with fuse holder

15 Mains switch. Turns the device on and o.

16 Function and control buttons

[MENU] | Opens the main menu. Skips back to the previous menu item.

[UP] | Increases the displayed value by one

[DOWN] | Decreases the displayed value by one

[ENTER] | Selects an option of the respective operating mode, conrms the set value

17 [PS 2] | Connection sockets for the supplied USB keyboard or the USB adapter

18 [LOCK] | Safety key switch: switches the laser output on or o.

19 Safety cable eyelet

20 [REMOTE] | Connection for an optional remote safety switch (emergency stop)

21 [DMX OUT] | DMX output, designed as XLR chassis socket, 3-pin

22 [DMX IN] | DMX input, designed as XLR chassis plug, 3-pin

Connections and operating elements
