7 Operation
7.1 Starting the device
CAUTION!
Risk of injury due to unexpected movements of the device!
The device head may perform fast movements and generate very bright
light. This is the case immediately after the device is switched on, in
automatic or remote operation, and when a connected DMX controller
is switched o. Persons who are in the immediate vicinity of the device
may be injured or frightened by this.
Make sure that there are no obstacles within the movement range of
the mirror, and that no persons are in the immediate vicinity of the head
before switching it on and during its operation.
Switch o the device before any work is performed in the movement
range or immediate vicinity of the device, or if unauthorised persons are
in that area.
Connect the device to the power supply to start operation. After a few seconds, the
fans start to work, the head moves to the home positions for rotation (pan) and incli‐
nation (tilt). After a few more seconds, the device will perform the last automatic
show. The name of the set show appears on the display, e.g., ‘Show 1’ . If the device is
operated in master mode, the ‘MASTER’ status LED lights up. The device is now
operational.
7.2 Main menu
1. To enter the main menu, press [MENU].
2. To scroll between individual menu items, press [UP] and [DOWN]. To exit the
menu, press [MENU] again.
3. If no button is pressed for about 30 s, the menu will be exited automatically.
ð
All previous settings are retained even when the device is switched o and
disconnected from the mains.
4. To restart with default values, use the functions under ‘Reset’ in the main
menu.
1. In the main menu, navigate to the ‘DMX Address’ menu item.
2. To open the ‘DMX Address’ menu, press [ENTER].
3. Use [UP] and [DOWN] to select the ‘Set DMX address’ submenu.
4. Conrm your selection with [ENTER].
5. Use [UP] and [DOWN] to select an address between 1 and 512.
6. Conrm your selection with [ENTER].
ð
The desired address is saved.
7. To exit the menu, press [MENU], or wait 30 seconds.
Make sure that the address matches the conguration of your DMX controller.
How to use the main menu:
Setting the DMX address
Operation
BSW-350 LED
13
Moving Head
