Page 10

CHIP (CHANNEL INPUTS) AND CHOP (CHANNEL DIRECT OUTPUTS)

All inputs and outputs for Sigma are on AES 59 ‘Tascam’ standard D-Sub connectors. Each D-Sub carries up to four stereo

signals. The inputs and outputs are all operating at line-level. The direct channel outputs are sourced post-fader.

T

ypically, you would connect the outputs from your D/A converter into the CHIPs.

The CHOPs would be connected to your A/D to record back into the DAW.

A

creative use for Sigma could be using it to automate an analogue desk. This could be achieved by connecting the

i

nsert sends from the console into Sigma’s CHIPs and then connecting Sigma’s CHOPs into the insert returns of the

c

onsole.

MISCELLANEOUS CONNECTIONS

EXT, RTNS, TB - AES 59 ‘Tascam’ standard connections:

EXT - Provides a line-level stereo input available from an external source such as a professional CD player.

RTNS (A + B)- Provides connections for the stereo insert return signals of both Mix Bus A and Mix Bus B.

TB - Provides a line-level input from which you can connect the output from a talkback microphone

preamplifier.

MIX B, SENDS, H/P - AES 59 ‘Tascam’ standard connections.

MIX B - Stereo Mix Bus B outputs

SENDS - Provides connections for the stereo insert send signals of both Mix Bus A and MIx Bus B.

H/P - Provides a line-level stereo headphone output suitable for running a headphone feed into a cue mixer.

EXT, RTNS, T/B †

D-sub to

XLR-F

Loom

Connector Type: 25-way D-type Female

Pin Description

1 n/c

XLR-814 n/c

2 0V

15 Talkback Mic Input (+ve)

XLR-73 Talkback Mic Input (–ve)

16 0V

4 Mix B Insert Return Right (+ve)

XLR-617 Mix B Insert Return Right (–ve)

5 0V

18 Mix B Insert Return Left (+ve)

XLR-56 Mix B Insert Return Left (–ve)

19 0V

7 Mix A Insert Return Right (+ve)

XLR-420 Mix A Insert Return Right (–ve)

8 0V

21 Mix A Insert Return Left (+ve)

XLR-39 Mix A Insert Return Left (–ve)

22 0V

10 External Input Right (+ve)

XLR-223 External Input Right (–ve)

11 0V

24 External Input Left (+ve)

XLR-112 External Input Left (–ve)

25 0V

13 n/c

MIX B, SENDS, H/P †

D-sub to

XLR-M

Loom

Connector Type: 25-way D-type Female

Pin Description

1 Headphone Right (+ve, line level)

XLR-814 Headphone Right (–ve, line level)

2 0V

15 Headphone Left (+ve, line level)

XLR-73 Headphone Left (–ve, line level)

16 0V

4 Mix B Insert Send Right (+ve)

XLR-617 Mix B Insert Send Right (–ve)

5 0V

18 Mix B Insert Send Left (+ve)

XLR-56 Mix B Insert Send Left (–ve)

19 0V

7 Mix A Insert Send Right (+ve)

XLR-420 Mix A Insert Send Right (–ve)

8 0V

21 Mix A Insert Send Left (+ve)

XLR-39 Mix A Insert Send Left (–ve)

22 0V

10 Mix B Output Right (+ve)

XLR-223 Mix B Output Right (–ve)

11 0V

24 Mix B Output Left (+ve)

XLR-112 Mix B Output Left (–ve)

25 0V

13 n/c
