P8 – Manual

8

Internal Linear Power Supply with Shielded Toroidal Transformer

Operating voltage for analog audio +/- 17 V

Operating voltage for relays und LEDs +18 V

Phantom power +48 V

Operating voltage for AD converter +12 V/+3,3 V

Mains Power Supply

Mains voltage (selectable, see fuse chamber) 230 V AC / 50 Hz; 115 V AC / 60 Hz

Fuse 230 V T 315 mA

Fuse 115 V T 630 mA

Power consumption max. 27 VA

Analog inputs & outputs; XLR & DB25 (balanced)

Maximum input gain (Mic, +8 dB to +62 dB) 13.5 dBu (33.5 dBu with PAD)

Input impedance (Mic/Line) 10 kΩ

Output impedance 75 Ω

Frequency range 15 Hz – 200 kHz

Equivalent Input Noise (EIN) -124 dBu

Noise (A-weighted, Mic Preamp, 150 Ω, 30 dB Gain) -94 dBu

Rausc (A-weighted, Mic Preamp, 150 Ω, 62 dB Gain) -66 dBu

Common mode rejection (1 kHz) < 78 dB

THD+N Ratio (1 kHz), Mic 30 dB Gain 0.003 %

THD+N Ratio (1 kHz), Mic 62 dB Gain (max.) 0.022 %

Signal display Green -25 dBu

Yellow 0 dBu

Red +19 dBu (without AD converter)

+12 dBu / -3 dBFs (with AD converter)
