1. Lint Filter Guard (optional)
2. Lint Filter
Figure 1
WARNING
To reduce the risk of fire and risk of lint collecting
in exhaust duct, do not operate dryer without lint fil-
ter in place.
W771
NOTE:NOTE: The Lint Filter Guard is an optional accessory to helpThe Lint Filter Guard is an optional accessory to help
prevent items from falling in the lint filter.prevent items from falling in the lint filter.
3. Load dryer half full with laundry ( 18 pounds [8.2 kg]
maximum dry clothes load). Add fabric softener sheet, if
desired, except with steam cycles.
WARNING
To reduce the risk of fire, explosion, serious injury
or death, clothes which have traces of any flamma-
ble substances such as cooking oil, machine oil,
flammable chemicals, thinner, etc. must not be put
into the dryer.
W131
NOTE:NOTE: To avoid damage to dryer, do not use more than oneTo avoid damage to dryer, do not use more than one
fabric softener sheet per load.fabric softener sheet per load.
D666I_SVG
4. Close loading door. Dryer will not operate with the door
open.
D668IE0A
5. If not already on (control lights will be lit), turn on the dry-
er by pressing the Power/Cancel button.
NOTE:NOTE: You will not be able to press the Start/Pause buttonYou will not be able to press the Start/Pause button
to Pause the cycle until the motor is running. If the Start/to Pause the cycle until the motor is running. If the Start/
Pause button is pressed while attempting to run the motorPause button is pressed while attempting to run the motor
(during the warm-up period), an invalid keypress tone will(during the warm-up period), an invalid keypress tone will
sound.sound.
6. Select the Cycle and, if desired, change the Selections
and Options settings. Follow garment manufacturer’s
care labels for recommended temperature settings.
7. Press the Start/Pause button to begin the cycle.
WARNING
To prevent the risk of fire, never stop a dryer before
the end of the drying cycle unless all items are
quickly removed and spread out so that the heat is
dissipated.
W756
IMPORTANT:IMPORTANT: The final part of dryer cycle occurs without heatThe final part of dryer cycle occurs without heat
(cool down cycle) to ensure that items in dryer are left at a(cool down cycle) to ensure that items in dryer are left at a
temperature that ensures that the items will not be dam-temperature that ensures that the items will not be dam-
aged.aged.
NOTE:NOTE: To stop dryer at any time, open the door or press theTo stop dryer at any time, open the door or press the
Start/Pause button. To restart dryer, close door and pressStart/Pause button. To restart dryer, close door and press
the Start/Pause button again.the Start/Pause button again.
8. Remove laundry immediately after dryer stops at end of
cycle.
DRY2544N_SVG
Optional Drying Rack
A drying rack, Part No. D512082, is available at extra cost
through your Factory Authorized Service Center.
The drying rack can be used in Manual cycles (Time Dry or
Quick Dry) only for no-tumble drying of articles such as ten-
nis shoes, sweaters, stuffed toys or other delicate items.
Operating Your Dryer
© Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
14 Part No. D518541ENR6
