Control Identification
Select Wash Temp Pads
SELECT WASH TEMP pads are used to select the temperature
of the water used for the wash fill. These pads include COLD,
WARM and HOT. These pads allow the user to select a water
temperature other than the default setting (COLD).
NOTE: Cycles are picked by selecting a Wash, Cycle
and Temp pad.
Select Cycle Modifier Pads
The Cycle Modifier pads are used to select cycle modifier op-
tions. The REGULAR option is the default and indicates no cycle
modifiers are active. The DELUXE and ULTRA options can be
programmed to offer extra features for an added vend price. Fea-
tures available include an added prewash, extra wash time, an
added extra rinse, extra rinse time and a warm rinse temperature.
FLW1556C_SVG1
Cycle
Wash
Temp
ULTRADELUXEREGULAR
DELICATESYNTHETICNORMAL
HOT
START
WARMCOLD
1
8
3
4
5
6
7
2
1. LED Light
2. SELECT CYCLE pads
3. Six 7-Segment Digits
4. Display
5. LED Status Lights
6. SELECT Cycle Modifier pads
7. START pad
8. SELECT WASH TEMP pads
Figure 1
Control Identification
©
Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
14 Part No. 807870ENR4
