39
User name and password: sender’s user name and password.
Server Address: The SMTP IP address or host name.
Select the secure connection type at the “Secure Connection” pull-down list according to what’s required.
SMTP Port: The SMTP port.
Send Interval(S): The time interval of sending email. For example, if it is set to 60 seconds and multiple motion detection alarms are
triggered within 60 seconds, they will be considered as only one alarm event and only one email will be sent. If one motion alarm
event is triggered and then another motion detection alarm event is triggered after 60 seconds, two emails will be sent. When
different alarms are triggered at the same time, multiple emails will be sent separately.
Click the “Test” button to test the connection of the account.
Recipient Address: receiver’s e-mail address.
4.4.12 FTP
After an FTP server is set up, captured pictures from events will be uploaded to the FTP server.
Go to NetworkFTP.
Click “Edit and Test” and then click “Add” to add the information of the FTP. After that, click “Save” to save the settings.
Server Name: The name of the FTP server.
Server Address: The IP address or domain name of the FTP.
Upload Path: The directory where files will be uploaded to.
Port: The port of the FTP server.
Use Name and Password: The username and password that are used to login to the FTP server.
4.4.13 HTTP POST
Go to ConfigNetwork HTTP POST interface.
Click “Edit” and then check “Enable”, select protocol type and set the server address (IP address/domain name), server port and
heartbeat interval.
