14 AFTER SALES SUPPORT 0345 605 2067 of 25 V3.5: 11/23
PREPARE
Install the shoulder strap
Fix the hook of the shoulder strap into the lifting lug on
the handle pole of the appliance.
WARNING!
It’s a quick release shoulder strap, the appliance
can be removed quickly from body when it’s in
emergency.
Adjust the pole length
Adjust the length of the pole saw according to
working situation.
Pull the lever of the quick clip to release the pole.
-- Push backwards the button(A) then loosen the
locking nut to unlock position, then adjust the pole
to desired pole length.
-- Turn locking nut to the lock position.
Adjust the blade head
The pole chain saw head can be rotated for different
cutting angles from 0º to 30º.
Turn the adjusting knob for head angle
counterclockwise to loosen the head. Adjust the head
to the desired position.
Remove the bar sheath
3
4
5
2
A
lock
unlock
push
