15 of 26
V3.5: 11/23
AFTER SALES SUPPORT 0345 605 2067
WARNING:
It’s a quick release shoulder strap, the appliance
can be removed quickly from body when it’s in
emergency.
Assembly the pole hedge trimmer
Before using the pole hedge trimmer, a one-time
assembly is required. When removed from the box,
the two parts are disconnected as shown in photo
below.
i. Assembly the working head to the telescopic
pole handle.
When inserted, the working head (A) would have
to target the telescopic pole handle (B), and must
be inserted fully. Turn the lock nut (C) to lock, and
must be locked fully.
Disassemble the working head from the telescopic
pole handle. Push the locker button(D), then turn
locker (C) anticlockwise to unlock, then pull the
handle out for removing.
ii. Attach the shoulder strap
Fix the hook of the shoulder strap into the lifting lug
on the handle pole of the appliance.
2
ASSEMBLY
A BC
lock fully
CD
lock
unlock
