Je bekijkt pagina 12 van 19
000
2. Basic Operation: Creating and Editing Setup Data
12
Item Description
Image: [Select]
button
Selects an image to display in the button.
Tap the [Select] button to display the image selection dialog.
Preregistered images are displayed on the [Preset] tab. To use an image, select the
image and tap the [OK] button.
Images registered by a user are displayed on the [User] tab. To use an image,
select the image and tap the [OK] button.
To upload an image file
1 Tap the [Upload Image] button in the image selection dialog.
A file selection dialog appears.
2 Select an image file.
The image is uploaded.
To delete an uploaded image file
1 Select the image file to delete on the [User] tab, and tap the [Delete Image]
button.
2 Tap the [Yes] button in the confirmation dialog.
Image: [Unset]
button
Releases the use of an image specified using the [Select] button.
Select the image on the edit screen, and tap the [Unset] button to release the use of
the image.
Hardware Key Leave this field blank for normal operation. If a value has been entered, tap the field
and remove the setting.
Command Selects the function to assign to the button. The setting will vary according to the
function.
For details, see the “Button function and configuration items” section.
Button function and configuration items
For details about each function, refer to the User’s Guide for the switcher.
Button function Configuration item Description Input value
– – No function is assigned. –
Shotbox Recall Reg No. Number of target register to recall 1 to 99
Snapshot Recall Region Target region to recall Select one of the
following:
M/E1 to M/E5, P/P
Reg No. Number of target register to recall 1 to 99
Macro Recall Macro No. Number of target macro to recall 1 to 999
Macro Take – – –
Rewind – – –
Run – – –
Button function Configuration item Description Input value
XPT (M/E) M/E Target M/E to switch Select one of the
following:
P/P, M/E1 to M/E5, P/P
Sub, M/E1 Sub to M/E5
Sub
Bus Target bus to switch Select one of the
following:
A-Bus, B-Bus, Util1 to 2,
Key1 Fill to Key8 Fill, Key1
Src to Key8 Src
Pair No Pair number to switch 1 to 300
XPT (AUX) Bus Target AUX bus to switch Select one of the
following:
Aux1 to Aux48
Pair No Pair number to switch 1 to 300
Transition M/E Target M/E row for transition Select one of the
following:
P/P, M/E1 to M/E5, P/P
Sub, M/E1 Sub to M/E5
Sub
Action Transition execution target and
action
Select one of the
following:
Cut, Auto Trans, Key1 to 8
On, Key1 to 8 Trans
[Note]
Only Cut and Auto Trans
can be selected if an M/E is
configured as P/P Sub or
M/E1 Sub to M/E5 Sub.
4 Repeat steps 2 and 3 to create other buttons.
5 Press and hold a bank selection button.
