7
GB
GB
1, 2, 3 (HDD REC)*
6
USB device port ( 3 USB HDD device for
REC feature)
USB port 1 and 2 support High Speed USB
(USB 2.0)
USB port 3 supports Super Speed USB (USB 3.1
Gen 1)
CAM (Conditional Access Module) slot
LAN
10BASE-T/100BASE-TX connector (Depending
on the operating environment of the network,
connection speed may differ. The
communication rate and quality are not
guaranteed.)
Power, Product Fiche and others
Power requirements
220 V - 240 V AC, 50 Hz
Energy Efficiency Class*
7
XR-85X9xJ: A
XR-75X9xJ: A
XR-65X9xJ: B
Screen size (measured diagonally) (Approx.)
XR-85X9xJ: 214.8 cm / 85 inches
XR-75X9xJ: 189.3 cm / 75 inches
XR-65X9xJ: 163.9 cm / 65 inches
Power consumption*
7
In [Standard] mode
XR-85X9xJ: 221 W
XR-75X9xJ: 206 W
XR-65X9xJ: 173 W
Annual energy consumption*
7
*
8
XR-85X9xJ: 307 kWh per year
XR-75X9xJ: 286 kWh per year
XR-65X9xJ: 240 kWh per year
Standby power consumption*
7
*
9
*
10
XR-85X9xJ: 0.50 W (35 W in software/
EPG update mode)
XR-75X9xJ: 0.50 W (33 W in software/
EPG update mode)
XR-65X9xJ: 0.50 W (34 W in software/
EPG update mode)
Display resolution (horizontal × vertical) (pixels)
3840 × 2160
Output rating
500 mA (for USB 1/2), 900 mA (for USB 3)
Dimensions (Approx.) (w × h × d) (cm)
with Table‐Top Stand
Standard position:
XR-85X9xJ: 188.8 × 109.8 × 45.0
XR-75X9xJ: 166.7 × 97.4 × 39.0
XR-65X9xJ: 144.3 × 84.8 × 33.8
Narrow position:
XR-85X9xJ: 188.8 × 111.0 × 45.0
XR-75X9xJ: 166.7 × 98.5 × 39.0
Soundbar position:
XR-85X9xJ: 188.8 × 115.8 × 45.0
XR-75X9xJ: 166.7 × 103.4 × 39.0
XR-65X9xJ: 144.3 × 90.8 × 33.8
without Table-Top Stand
XR-85X9xJ: 188.8 × 108.6 × 6.1
XR-75X9xJ: 166.7 × 96.1 × 6.1
XR-65X9xJ: 144.3 × 83.5 × 6.6
Stand width (Approx.) (cm)
Standard position:
XR-85X9xJ: 188.7
XR-75X9xJ: 166.6
XR-65X9xJ: 144.2
Narrow position:
XR-85X9xJ / 75X9xJ: 61.0
Soundbar position:
XR-85X9xJ: 188.7
XR-75X9xJ: 166.6
XR-65X9xJ: 144.2
Mass (Approx.) (kg)
with Table-Top Stand
XR-85X9xJ: 51.2
XR-75X9xJ: 39.1
XR-65X9xJ: 28.5
without Table-Top Stand
XR-85X9xJ: 48.7
XR-75X9xJ: 36.8
XR-65X9xJ: 27.5
Others
Optional accessories
Wall-Mount Bracket: SU-WL850
(XR-75X9xJ / 65X9xJ only)
Wall-Mount Bracket: SU-WL450
Operating temperature: 0 ºC – 40 ºC
Operating humidity: 10 % – 80 % RH (non-
condensing)
*1 When 4096 × 2160p is input and [Wide mode] is set
to [Normal], the resolution is displayed as 3840 ×
2160p. To display 4096 × 2160p, set [Wide mode]
setting to [Full 1] or [Full 2].
*2 Refer to the on screen menu to set [HDMI signal
format].
*3 Refer to the online Help Guide for details.
*4 HDMI IN 3 & 4 only. Use the Ultra High Speed HDMI
Cable to connect.
*5 Connect your audio system to the HDMI IN 3 to
route TV audio to your audio system.
*6 Function not available in Italy.
*7 This information is for EU and other countries
whose relevant regulation is based on EU energy
labelling regulation.
