Notes

 When “Out. Image(Single)” (page 87) in the

“Enhanced Out.” menu is set to “Fixed”, “Side

by S

ide” cannot be set to On.

 XYZ format signals are not supported.

 Only one channel can be displayed at a time for

each input terminal. For example, if you set the

same SDI input connector 1 for “Ch.1” and

“Ch.2,” they cannot be displayed at the same

time. To compare the same image with

different channel settings, use another

connector for the input of connector 1 image

and set the same input connector for “Ch.2.” If

a combination is determined invalid for

simultaneous display, Screen A will show

available images to display. In this case, Screen

B turns black and shows an “Invalid Input

Combination” message.

 Even if the input terminals are different, it may

not be possible to display inputs at the same

time. For the combinations that can be

displayed at the same time, see “Displayable

combination of Side by Side for SDI/IP input”

(page 66).

 The time code is displayed for only an SDI/IP

stream (ancillary data) that is input to Screen A.

 The audio signal input to Screen A is output

from the headphones jack, or AUDIO output

connector. (BVM-HX3110 only)

 The drive frequency of the panel will be the

same as Screen A.

 “Native Scan” and “Under Scan” are

automatically set to “Off.”

 When the input signal of each screen is HDMI,

it cannot be output to Enhanced Monitor Out.

 “Conversion Assign” is available when the paid

optional “BVML-H10” license (sold separately)

is enabled.

 “EMO Assign” is available when one of the paid

optional “BVML-H10”, “BVML-S10” or “BVML-

T10” licenses (sold separately) is enabled.

User LUT Assign When the User LUT data is applied to a

setting channel, select the screen with

the data applied. (Default value:

een B)

 Screen A&B: When the channels set

for Screen A and Screen B are the

same, User LUT is applied to Screen

A and Screen B.

Example in which the channels set

Screen A and Screen B are the

same:

Screen A: Ch.1 4K SDI Input1

Screen B: Ch.1 4K SDI Input1

When the channels set for Screen A

and S

een B are different and the

input signal set for either channel is

4K SDI, 4K IP stream or HDMI (4K

equivalent), User LUT is applied

preferentially for Screen B.

Example in which the channels set

Screen A and Screen B are

different:

Screen A: Ch.1 4K SDI Input1

Screen B: Ch.2 HDMI

 Screen A: User LUT is applied only to

Screen A.

 Screen B: User LUT is applied only to

Screen B.

When the setting channels of Screen A

and Scr

n B are the same and the

input signal setting of the setting

channel is HDMI (4K equivalent), User

LUT is fixed to “Screen A&B” regardless

of the setting value.

Note

If the channels set for Screen A and

Screen B are different and the input

signal set for both channels is 2K SDI,

2K IP stream or HDMI (2K equivalent),

“User LUT Assign” cannot be selected.

Screen A and Screen B are displayed

with the User LUT setting of each set

channel applied.

Conversion Assign When the Conversion (HDR SDR

version) function is enabled, select

the display screen to be applied.

(Default value: Screen B)

 Screen A

 Screen B

EMO Assign Select the display screen that will be

the input image o

f the SDI signal

output from the Enhanced Monitor Out

terminal. (Default value: Screen B)

 Screen A

 Screen B

Submenu Setting
