56
False Color
Divides the brightness level of the input signal
into 12 color palettes and displays them in
different colors.
The brightness of the image captured on the
c
ame
ra is displayed in different colors according
to the signal level to make elements easier to
identify visually and allow for easier iris
recognition.
This prevents blown out highlights and blocked
out
shad
ows, and preserves the colors needed
for grading.
Notes
False Color is applicable only when a signal
with a resolution of 1280×720 or higher is input.
False Color is temporarily turned off when
adjusting Gain/Bias of Internal Signal and User
Color Temp.
ALM is temporarily turned off.
The Transparency setting for WFM, Vector
Scope, and Time Code is temporarily set to
Black.
Mono, Blue Only, RGB Cutoff, and Chroma Up
are forcibly turned off.
When False Color1 of Screen A is set to On,
Camera Focus is forcibly turned off. (Even when
False Color2 of Screen B is set to On, Camera
Focus is not forcibly turned off.)
False Color is also applied to Time Code and
Closed Caption.
The image adjustment process is applied to
images for which False Color was used and the
scale part of False Color. However, Chroma is
not applied when EOTF is set to 2.2, 2.4, 2.6,
CRT or 2.4(HDR).
When IMD or Picture Out Disp. is On, the False
Color display is temporarily disabled. The False
color scale is not displayed either.
Zoom When “On” is selected while the WFM
(Wave Form Monitor) is displayed, the
low gradation area is enlarged. When
“On” is selected while the Vector Scope
(vector scope) is displayed, the black
area is enlarged.
Scale: Select the enlargement scale
for Zoom. Select 20% to enlarge
a 0 to 20% area of the signal
level and 30% to enlarge a 0 to
30% area of the signal level.
Submenu Setting
Submenu Setting
False Color1 Turns false color display On/Off.
(Def
ault value: Off)
This setting is applied to Single View
a
nd
Screen A in Quad View/Side by
Side.
On: Displays in false colors.
Off: Does not display in false colors.
Color Palette Selects the color palette to be applied
for f
alse color display. (Default value:
Preset1)
A preset between "Preset1" to
"P
re
set10" can be selected. The setting
data are assigned to each preset
between "Preset1" to "Preset10". See
“Color palette presets” (page 62) for
details.
The data for each can be changed.
Name Displays the color palette name.
False Color2 Turns false color display On/Off.
(
Def
ault value: Off)
This setting is applied to Screen B in
Quad
V
iew/Side by Side.
On: Displays in false colors.
Off: Does not display in false colors.
Color Palette Selects the color palette to be applied
for f
alse color display. (Default value:
Preset1)
A preset between "Preset1" to
"P
re
set10" can be selected. The setting
data are assigned to each preset
between "Preset1" to "Preset10". See
“Color palette presets” (page 62) for
details.
The data for each can be changed.
Name Displays the color palette name.
Scale Display Turns the false color scale display On/
Of
f.
(Default value: On)
On: Displays the scale.
Off: Does not display the scale.
