Handleiding

19

Power button

Rotary encoder/MANUAL buttons

The knobs are used to adjust the Gain and Bias of

“R/G

/B Gain” and “R/G/B Bias” in “User Color

Temp.”. The MANUAL buttons are used to reset

the adjustment values.

Numeric buttons

Function buttons

UP button

DOWN button

When the menu is displayed, press the

button to select a menu item or setting

value.

The menu cursor's moving direction of

the uni

t ca

n be selected (page 86).

Button Operations

MONITOR

switch

Switches the unit status.

The unit enters sleep mode if this is

pr

ess

ed when the unit is in on. The

Power indicator and STATUS indicator

on the front panel of the unit light up

in red.

Press the switch for On mode when

the uni

t is

in sleep mode.

Knob Operations

CONTRAST knob Adjust the contrast.

BRIGHT knob Adjust the brightness.

CHROMA knob Adjust the color intensity.

PHASE knob Adjust the sharpness.

Button Operations

CONTRAST MANUAL

bu

tton

Pr

ess to manually adjust the contrast.

BRIGHT MANUAL

button

Pr

ess to manually adjust the

brightness.

CHROMA MANUAL

bu

tton

Pr

ess to manually adjust the color

intensity.

PHASE MANUAL

bu

tton

Pr

ess to manually adjust the

sharpness.

Button Operations

1 to 9 button The functions assigned to the numeric

but

tons from 1 to 9 on the controller

are operated.

The factory default settings are

f

ollow

ing:

1 button: Ch.1

2 button: Ch.2

3 button: Ch.3

4 button: Ch.4

5 button: WFM

6 button: Native Scan

7 button: Internal Signal

8 button: Int. Signal Pattern

9 button: Marker

You can assign the various functions

un

de

r “F/Num. Key Setting” (page 72)

of “Controller” in the “F Key Setting”

m

enu.

Ent b

utton Operates similar to the ENTER button

on

the

controller.

Button Operations

F1 to F16 button The functions assigned to the function

b

utt

ons on the controller are operated.

The following functions are available.

Mono, Blue Only, Native Scan, R Off, G

Of

f,

B Off, Character Off, Interlace,

Chroma Up, Pixel Zoom, Marker,

Aspect Marker, Area Marker1, Area

Marker2, Center Marker, Aspect

Marker-Line, Asp. Blank.-Half, Asp.

Blank.-Black, Side by Side, ALM, Time

Code, Aperture
