SNT EX101/SNT EX104/SNT EP104
Operating the unit
Configuration of Main Viewer
14
(Capture)
Click to capture a still image shot by the camera and to
store it in the computer. Click to open the folder to be
saved.
Note
In the case of Windows Vista, Windows 7, Windows 8
or Windows 8.1, if “Enable Protected Mode” is checked
in Control Panel-Internet Option-Security, still images
cannot be shot.
(Run)/ (Stop Save Video)
Runs and stops Save Video. Click to open the folder
to be saved.
Note
In the case of Windows Vista, Windows 7, Windows 8
or Windows 8.1, if “Enable Protected Mode” is checked
in Control Panel-Internet Option-Security, video
content cannot be saved.
Volume
(Displayed when Audio codec (page 28) is set to On.)
Adjust the microphone volume by moving the each
slider bar.
When you click , the icon changes to and the
microphone input stops. To input the microphone, click
again.
When you click , the icon changes to and the
microphone output stops. To output the microphone,
click again.
Notes
• This operation is not available on the SNT-EP104 or
SNT-EP154.
• Voice alert configuration is only available for CH1 on
the SNT-EX154.
Camera control panel
On this panel, you can control the pan/tilt/home position
of the camera, adjust the zoom and switch focus mode
(page 16). In addition, you can obtain authority to
operate the camera when the exclusive control mode is
on.
Notes
• This operation is not available on the SNT-EP104 or
SNT-EP154.
• To operate the camera, it is necessary to have a camera
connected, and the connection/setting set correctly.
Pan/Tilt control
Click the arrow button the direction in which you want
to move the camera. Keep it pressed to move the camera
continuously.
Zoom control
Press to zoom out, and press to zoom in.
Zooming continues while the button remains pressed.
Focus control
To focus on a nearby object, press . To focus on a
distant object, press .
By pressing , focus is set to the optimum
position.
Note
To control the focus manually, set Focus mode of the
Camera menu to Manual (page 28).
(Exclusive control)
Click this button to display the time remaining for
operation authority. However, if operation authority has
not been obtained, the waiting time is displayed.
Trigger panel
The above is displayed only when Viewer mode
(page 49) is set to Full, and one or more triggers are
enabled in the Trigger menu (page 70).
